Drum-Tec Multicore Transparent Drum Trigger Cable Set

drum-tec Transparent Trigger Multicore 12-Cable Snake

• Universal trigger cable harness with 12 stereo trigger cables
• Transparent
• Every cable features clearly visible marks at each end by the use of a number 1… to 12
• One end with a straight stereo jack (for the module input)
• The other end with angled stereo jack (for pad/cymbal trigger output)
• The total length of the multicore cable suits for a medium to a large e-drums setup like Roland TD-12/20/25/30/50, drum-tec diabolo and pro series, Roland MDS racks (MDS-12/20/25/50K,50KV) etc.
• The length of the single cables are optimized for e-drum use
• Overall diameter of all cables about 5-6 cm
• Diameter per single cable approx. 4 mm

1. Hi Hat cable: 130 cm
2. Hi Hat control cable: 130 cm
3. Kick cable: 200 cm
4. Snare cable: 140 cm
5. Tom 1 cable: 200 cm
6. Tom 2 cable: 260 cm
7. Tom 3 cable: 330 cm
8. Tom 4 cable: 400 cm
9. Crash 1 cable: 210 cm
10. Crash 2 cable: 320 cm
11. Ride cable: 360 cm
12. Ride Edge cable: 360 cm
